TECHNICAL DATASHEET

  • Asymmetrical optic for street, urban and green areas lighting.
  • Asymmetrical optic for wide urban road and cycle-path lighting
  • Colour temperature: 4000K, 3000 K  (others in option)
  • Rated voltage 220÷240V 50/60Hz
  • Power factor >0,95
  • CRI ≥ 70
  • LED source efficiency: 185 lm/W  4000K
  • Insulation class II, I
  • Protection degree IP66 | IK09 total
  • Weight max 7 kg
  • Mounting Pole mounted
  • LED Modules Removable / Replaceable.
  • Operating temp. -40°C / +55°C
  • Storage temp -40°C / +80°C
  • Main standards
  • EN 60598-1, EN 60598-2-3, EN 62471,
  • EN 55015, EN 61547, EN 61000-3-2, EN-61000-3-3
